TMS320F2812PGFA

digital signal processor, QFP, – 0.3 V to 4.6 V, High-Performance Static CMOS Technology

Rated 5 Rating 5 | reviews | Write a review

Price:: US $20.00~25.00 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
	US $20.00~25.00

PartNumber:: TMS320F2812PGFA

Brand:: Texas Instruments - TI | Pack: QFP | D/C: 07+

Availability:: Supply Ability: 10000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Sold By

Mr. Jason's store

(China (Mainland))

add to my favourite

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2011-07-22

From Other Seller

Part Number:TMS320F2812PGFA
US $20.00 - 25.00
TMS320C6414TBGLZA7

US $58.00 - 65.00 / Piece
(0) Remove
74AHC2G08VS SOP-8

US $2.00 - 2.00 / Piece
(0) Remove
Quantity:

piece

Product Summary

The TMS320F2812PGFA is a digital signal processor.

Parametrics

TMS320F2812PGFA absolute maximum ratings: (1)Supply voltage range, VDD, PLLVCCA, VDDO, and VCCA: – 0.3 V to 4.6 V; (2)Supply voltage range, CVDD: – 0.5 V to 2 V; (3)VCCP range: – 0.3 V to 3.6 V; (4)Input voltage range, VIN: – 0.3 V to 4.6 V; (5)Output voltage range, VO: – 0.3 V to 4.6 V; (6)Output voltage range,VO: – 0.3 V to 4.6 V; (7)Input clamp current, IIK (VIN < 0 or VIN > VCC): ± 20 mA; (8)Output clamp current, IOK (VO < 0 or VO > VCC): ± 20 mA; (9)Operating free-air temperature ranges, TA: A version: – 40℃ to 85℃, S version: – 40℃ to 125℃; (10)Junction temperature range, TJ: – 40℃ to 150℃; (11)Storage temperature range, Tstg: – 65℃ to 150℃.

Features

TMS320F2812PGFA features: (1)High-Performance Static CMOS Technology: 150 MHz (6.67-ns Cycle Time), Low-Power (1.8-V Core, 3.3-V I/O) Design, 3.3-V Flash Programming Voltage; (2)High-Performance CPU (C28x): 16 x 16 and 32 x 32 MAC Operations, 16 x 16 Dual MAC, Harvard Bus Architecture, Atomic Operations, Fast Interrupt Response and Processing, Unified Memory Programming Model, 4M Linear Program Address Reach, 4G Linear Data Address Reach, Code-Efficient (in C/C++ and Assembly), TMS320F24x/LF240x Processor Source Code Compatible; (3)On-Chip Memory: Up to 128K x 16 Flash (8 x 4K and 6 x 16K Sectors), 2K x 16 OTP ROM, L0 and L1: 2 Blocks of 4K x 16 Single-Access RAM (SARAM), H0: 1 Block of 8K x 16 SARAM, M0 and M1: 2 Blocks of 1K x 16 SARAM.
