AD9432BSQ-105

analog-to-digital converter, 12 bit, 20 mA, –0.5 V to VCC + 0.5 V, 67 dB

Rated 5 Rating 5 | reviews | Write a review

Price:: US $20.00~25.00 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
	US $20.00~25.00

PartNumber:: AD9432BSQ-105

Brand:: Analog Devices - ADI | Pack: QFP | D/C: 04+

Availability:: Supply Ability: 10000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Sold By

Mr. Jason's store

(China (Mainland))

add to my favourite

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2012-03-29

From Other Seller

Part Number:AD9432BSQ-105
US $20.00 - 25.00
HCPL-7800A

US $2.50 - 4.10 / Piece
(0) Remove
MOC3063

US $0.32 - 1.50 / Piece
(0) Remove
Quantity:

piece

Product Summary

The AD9432BSQ-105 is a 12-bit monolithic sampling analog-to-digital converter with an on-chip track-and-hold circuit and is optimized for high-speed conversion and ease of use. The AD9432BSQ-105 operates at a 105 MSPS conversion rate with outstanding dynamic performance over its full operating range. The applications of the AD9432BSQ-105 include Communications, Basestations and Zero-IF Subsystems, Wireless Local Loop (WLL), Local Multipoint Distribution Service (LMDS) and HDTV Broadcast Cameras and Film Scanners.

Parametrics

AD9432BSQ-105 absolute maximum ratings: (1)VDD: 6 V; (2)VCC: 6 V; (3)Analog Inputs: –0.5 V to VCC + 0.5 V; (4)Digital Inputs: –0.5 V to VDD + 0.5 V; (5)VREFIN: –0.5 V to VCC + 0.5 V; (6)Digital Output Current: 20 mA; (7)Operating Temperature: –55 to +125℃; (8)Storage Temperature: –65 to +150℃; (9)Maximum Junction Temperature: 150℃; (10)Maximum Case Temperature: 150℃.

Features

AD9432BSQ-105 features: (1)On-Chip Reference and Track/Hold; (2)On-Chip Input Buffer; (3)850 mW Typical Power Dissipation at 105 MSPS; (4)500 MHz Analog Bandwidth; (5)SNR = 67 dB @ 49 MHz AIN at 105 MSPS; (6)SFDR = 80 dB @ 49 MHz AIN at 105 MSPS; (7)2.0 V p-p Differential Analog Input Range; (8)Single 5.0 V Supply Operation; (9)3.3 V CMOS/TTL Outputs; (10)Two’s Complement Output Format.
