HD6417709F80BV

microprocessor, TQFP-208, –0.3 to 4.2 V

Rated 5 Rating 5 | reviews | Write a review

Price:: US $9.00~9.50 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
	US $9.00~9.50

PartNumber:: HD6417709F80BV

Brand:: Renesas Technology Corp - Renesas | Pack: TQFP | D/C: 09+

Availability:: Supply Ability: 10000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Sold By

Mr. Jason's store

(China (Mainland))

add to my favourite

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2011-05-23

From Other Seller

Part Number:HD6417709F80BV
US $9.00 - 9.50
TMS320C6414TBGLZA7

US $58.00 - 65.00 / Piece
(0) Remove
A50L-0001-0175

US $100.00 - 100.00 / Piece
(0) Remove
Quantity:

piece

Product Summary

The HD6417709F80BV is a single-chip RISC microprocessor that integrates a Renesas Technology-original RISC-type SuperHTM architecture CPU as its core that has an on-chip multiplier, cache memory, and a memory management unit (MMU) as well as peripheral functions required for system configuration such as a timer, a realtime clock, an interrupt controller, and a serial communication interface. This LSI includes data protection, virtual memory, and other functions provided by incorporating an MMU into a SuperH Series microprocessor (SH-1 or SH-2).

Parametrics

Absolute maximum ratings: (1)Power supply voltage (I/O), VccQ: –0.3 to 4.2 V; (2)Input voltage (except port L), Vin: –0.3 to VccQ + 0.3 V; (3)Input voltage (port L), Vin: –0.3 to AVcc + 0.3 V; (4)Analog power-supply voltage, AVcc: –0.3 to 4.6 V; (5)Analog input voltage, VAN: –0.3 to AVcc + 0.3 V; (6)Operating temperature, Topr: –20 to 75 ℃; (7)Storage temperature, Tstr: –55 to 125 ℃.

Features

Features: (1)Original Renesas Technology SuperH architecture; (2)Object code level with SH-1, SH-2, and SH-3 Series; (3)32-bit internal data bus; (4)RISC-type instruction set; (5)Instruction execution time: one instruction/cycle for basic instructions; (6)Logical address space: 4 Gbytes; (7)Space identifier ASID: 8 bits, 256 logical address space; (8)Five-stage pipeline.
