Product Summary

The TMS320C6414TGLZ is a DSP. It is the highest-performance fixed-point DSP generation in the DSP platform. The TMS320C6414TGLZ device is based on the second-generation high-performance very-long-instruction-word (VLIW) architecture developed by Texas Instruments (TI), making it an excellent choice for wireless infrastructure applications. The TMS320C6414TGLZ is a code-compatible member of the C600 DSP platform.

Parametrics

TMS320C6414TGLZ absolute maximum ratings: (1)Supply voltage ranges: CVDD: -0.5 V to 1.5 V; (2)DVDD: -0.5 V to 4.4 V ; (3)Input voltage ranges: (except PCI), VI: -0.5 V to 4.4 V; (4)(PCI), VIP: -0.5 V to DVDD + 0.5 V; (5)Output voltage ranges: (except PCI), VO: -0.5 V to 4.4 V; (6)(PCI), VOP [C6415T and C6416T only]: -0.5 V to DVDD + 0.5 V; (7)Operating case temperature ranges, TC: (default): 0 to 90℃; (8)Storage temperature range, Tstg: -65 to 150℃.

Features

TMS320C6414TGLZ features: (1)Highest-Performance Fixed-Point DSPs; (2)Two External Memory Interfaces; (3)Three Multichannel Buffered Serial Ports; (4)Three 32-Bit General-Purpose Timers; (5)Sixteen General-Purpose I/O (GPIO) Pins; (6)Flexible PLL Clock Generator; (7)Byte-Addressable (8-/16-/32-/64-Bit Data); (8)8-Bit Overflow Protection; (9)Bit-Field Extract, Set, Clear; (10)Normalization, Saturation, Bit-Counting; (11)VelociTI.2 Increased Orthogonality.

Diagrams

TMS320C6414TGLZ block diagram

Image Part No Mfg Description Data Sheet Download Pricing
(USD)
Quantity
TMS320C6414TGLZ7
TMS320C6414TGLZ7

Texas Instruments

Digital Signal Processors & Controllers (DSP, DSC) Fixed-Pt Dig Sig Proc

Data Sheet

Negotiable
