Product Summary

The CS5530A-UCE companion device is designed to work in conjunction with an AMD Geode GX1 processor. Together, the Geode GX1 processor and CS5530A-UCE companion device provide a system-level solution well suited for the high performance needs of a host of devices which include digital set-top boxes and thin client devices. The device is a PCI-to-ISA bridge (South Bridge), ACPIcompliant chipset that provides AT/ISA style functionality.

Parametrics

CS5530A-UCE absolute maxing ratings: (1)Operating Case Temperature: min=0, max=110℃; (2)Storage Temperature: min=-65℃, max=150℃; (3)Supply Voltage: 4.0 V; (4)Voltage On Any Pin: min=-0.5V, max=5.5 V; (5)Input Clamp Current, IIK: min=-0.5mA, max=10mA; (6)Output Clamp Current, IOK: max=25mA.

Features

CS5530A-UCE features: (1)Designed for use with AMD’s Geode GX1 processor; (2)352 PBGA (Plastic Ball Grid Array) package; (3)3.3V or 5.0V PCI bus compatible; (4)5.0V tolerant on all inputs; (5)3.3V core.

Diagrams
